Furuno – Class A AIS Transponder
Roll over image to zoom in
$2,390.00
The Furuno DRS12ANXT is a 12 kW Solid-State Doppler Radar Pedestal designed for professional and recreational vessels. It delivers advanced target tracking, precise detection, and reliable operation with no magnetron maintenance, ensuring maximum radar performance in all weather conditions.
Condition: New
The Furuno DRS12ANXT Doppler Radar Pedestal combines cutting-edge solid-state radar technology with Doppler processing to deliver unmatched accuracy and safety at sea. As part of Furuno’s NXT Series, it offers InstantTarget™ tracking, Fast Target Tracking™, and true color target differentiation to easily identify moving targets.
Operating without a magnetron, the DRS12ANXT requires minimal maintenance and provides consistent long-term performance. Designed for seamless integration with Furuno’s NavNet TZtouch, TZtouch2, and TZtouch3 systems, this radar pedestal supports open array antennas of 3.5 ft, 4 ft, and 6 ft lengths for flexible installation.
Key Features
-
12 kW Solid-State Doppler Radar Pedestal
-
Advanced Doppler processing for motion detection and target speed
-
InstantTarget™ and Fast Target Tracking™ technology
-
Solid-state transmitter: no magnetron replacement needed
-
True color target differentiation for better situational awareness
-
Compatible with Furuno NavNet TZtouch / TZtouch2 / TZtouch3
-
Compact, durable construction for harsh marine environments
-
Low power consumption and silent operation
Key Technical Specifications
| Specification | Details |
|---|---|
| Brand | Furuno |
| Model | DRS12ANXT |
| Radar Type | Solid-State Doppler Radar |
| Output Power | 12 kW Equivalent |
| Radar Frequency | X-Band (9.41 GHz) |
| Antenna Compatibility | 3.5 ft / 4 ft / 6 ft Open Array |
| Range | 0.125 nm – 96 nm |
| Rotation Speed | 24 / 36 / 48 rpm |
| Beam Width | Horizontal: 1.8° (4 ft), 1.35° (6 ft) |
| Waterproof Rating | IP26 (Pedestal Unit) |
| Power Supply | 24 V DC |
| Power Consumption | 60 W (typical) |
| Operating Temperature | -25°C to +55°C |
| Interface | Ethernet (RJ-45) |
| Weight | Approx. 20 kg (Pedestal only) |
Package Includes
-
DRS12ANXT Radar Pedestal
-
Mounting Hardware
-
User and Installation Manual
Compatibility
Compatible with: Furuno NavNet TZtouch / TZtouch2 / TZtouch3
Optional Accessories: 3.5 ft / 4 ft / 6 ft Open Array Antennas, 10 m / 15 m / 20 m Radar Cables
