Siglent SPS5162X DC Power Supply, Single Output, 160 V, 15 A, 720 W, Switch Mode, SPS5000X Series

Siglent SPS5162X DC Power Supply: Precision Power for Demanding Applications

Overview

The Siglent SPS5162X is a programmable single-output DC power supply designed to deliver 160V, 15A, and up to 720W of clean, stable power for the most demanding R&D and production applications. With advanced features like adjustable slew rates, series/parallel operation, and comprehensive protection functions, it empowers engineers to conduct accurate and safe testing.

Explore more DC Power Supplies

Key Features

• Output: Single channel, 160V / 15A / 720W

• High precision: Voltage & current resolution down to 1 mV / 1 mA

• Fast Transient Response: Recovery within 2ms

• Adjustable slew rate: Voltage: 0.1–320V/s | Current: 0.01–30A/s

• Series/Parallel Operation: Up to 3 units in parallel or 2 in series

• Protection Modes: OVP, OCP, OTP, LPP, and Low AC input protection

• Interfaces: USB Host/Device, LAN, and optional GPIB

• Compact design: Ideal for benchtop or rack-mount setups

Compare with other Single DC Power Supplies

Technical Specifications (Highlights)

• Line/Load Regulation: 80 mV (CV), 19 mA (CC)

• Ripple & Noise: 80 mV p-p (CV), 30 mA (CC)

• Voltage Programming Accuracy: 0.1% ± 100 mV

• Current Programming Accuracy: 0.1% ± 15 mA

• Remote Sensing: Supported

• Control Modes: CV/CC/ERR/ON/OFF Status via photo coupler

• Efficiency: >82% at 200Vac input

• Digital Display: 2.4” screen with 170° viewing angle

Interface & Connectivity

• LAN (Ethernet): IP address configuration

• USB Type A/B: Host & Device modes

• GPIB: Optional via adapter

• External Analog Control: Voltage & current programming and monitoring

• Remote On/Off Control: Logic-level switchable

Value to the Customer

The Siglent SPS5162X provides a complete power solution that is:

• ✅ Precise and reliable, ideal for sensitive and high-power applications

• 🚀 Flexible and programmable, supporting automated sequences and remote control

• 🔐 Safe, with comprehensive protection for devices and users

• 💡 Versatile, supporting lab, industrial, and embedded systems use
