Tektronix TRCP0600: Precision Current Probe for High-Frequency Measurements

Features and Specifications: Tektronix TRCP0600 Current Probe, Rogowski, AC, 500 mA, 12 Hz to 30 MHz, 600 A, 100X, TRCP Series

Product Overview:

The Tektronix TRCP0600 is a high-performance Rogowski current probe designed for accurate and reliable current measurements in a wide range of applications. With its AC coupling, it is ideal for measuring AC currents from 12 Hz to 30 MHz.

Features:

AC coupling for accurate AC current measurements
Wide bandwidth of 12 Hz to 30 MHz
High sensitivity of 500 mA
Maximum current measurement of 600 A
100X attenuation ratio
Flexible Rogowski coil for easy placement around conductors
Compact and lightweight design

Current Range: 500 mA to 600 A
Bandwidth: 12 Hz to 30 MHz
Sensitivity: 500 mA
Attenuation Ratio: 100X
Accuracy: ±1%
Operating Temperature: 0°C to 50°C
Dimensions: 150 mm x 50 mm x 25 mm
Weight: 150 g

TRCP0600 Current Probe
User Manual

Accurate and reliable current measurements
Wide bandwidth for capturing high-frequency signals
High sensitivity for measuring small currents
Flexible coil for easy use in various applications
Compact and portable for convenient use

Value to the Customer:

The Tektronix TRCP0600 Current Probe provides exceptional value to customers by enabling them to:

Perform precise current measurements in a wide range of applications
Troubleshoot and diagnose electrical systems efficiently
Monitor and analyze current waveforms with high accuracy
Improve the safety and reliability of electrical systems
