Teledyne LeCroy T3AFG30: Precision Arbitrary Function Generator for Advanced Signal Generation
Roll over image to zoom in
$590.00
Teledyne LeCroy T3AFG30 Arbitrary Function Generator: 30 MHz, 150 MS/s, 16 kpts, 2 CH, T3AFG Series
Condition: New
Features and Specifications: Teledyne LeCroy T3AFG30 Arbitrary Function Generator
Product Overview:
The Teledyne LeCroy T3AFG30 is a high-performance arbitrary function generator designed for demanding applications in research, development, and testing. With its advanced features and exceptional specifications, it provides precise and versatile signal generation capabilities.
Features:
30 MHz Bandwidth: Generates signals up to 30 MHz with high accuracy and stability.
150 MS/s Sample Rate: Captures and reproduces fast-changing waveforms with exceptional fidelity.
16 kpts Memory Depth: Stores complex waveforms for extended playback and analysis.
2 Channels: Provides simultaneous generation of two independent waveforms.
Arbitrary Waveform Generation: Creates and outputs custom waveforms with precise control over shape, amplitude, and frequency.
Built-in Waveforms: Includes a library of common waveforms (sine, square, triangle, etc.) for quick and easy signal generation.
Modulation Capabilities: Supports AM, FM, PM, and FSK modulation for simulating real-world signal conditions.
Triggering and Synchronization: External triggering and synchronization options enable precise timing and coordination with other instruments.
Intuitive User Interface: Easy-to-use front panel and software interface simplify operation and waveform creation.
Specifications:
Frequency Range: 0.001 Hz to 30 MHz
Sample Rate: 150 MS/s
Memory Depth: 16 kpts per channel
Output Amplitude: 10 mVpp to 10 Vpp
Output Impedance: 50 ohms
Modulation Types: AM, FM, PM, FSK
Triggering: External, Internal, Manual
Synchronization: External, Master/Slave
What’s in the Box:
T3AFG30 Arbitrary Function Generator
Power cord
USB cable
Quick start guide
Benefits:
Precise and Reliable Signal Generation: Delivers accurate and stable signals for critical applications.
Versatile Waveform Creation: Enables the generation of complex and custom waveforms for testing and simulation.
Enhanced Modulation Capabilities: Simulates real-world signal conditions for testing and analysis.
Easy Operation and Control: Intuitive user interface simplifies operation and waveform creation.
Value for Customers: Provides a cost-effective solution for high-performance signal generation needs.
Additional information
| Brand | Teledyne LeCroy |
|---|
